列管式冷凝器
  我廠生產的列管冷凝器,按材質分為碳鋼列管冷凝、不銹鋼列管式冷凝器和碳鋼 與不銹鋼混合列管式冷凝三種,按形式分為固定管板式、浮頭式、U型管式換熱器, 按結構分為單管程、雙管程和多管程。傳熱面積0.5-500m2,可根據用戶需要定制。
公稱直徑管程數管子數量換熱面積 公稱值/計算值管程通道截面積 管程通道流速為0.5m/sec時的流量m/hr公稱壓力
管子長度φ25×2.5
15002000300040006000φ25×2
1591141.51.6222.1733.27

0.0044/0.0049

7.92/8.820.25
2191263/3.004/4.026/6.068/8.1 0.0082/0.009014.76/16.200.6
 2263/3.004/4.026/6.068/8.81 0.0041/0.00457.38/8.011.0
2731445/5.087/5.1810/10.2614/13.7221/20.630.0138/0.015224.84/27.361.6
 2405/4.626/6.199/9.3312/12.4719/18.760.0063/0.006911.24/12.422.5
3251607/6.939/9.2814/14.0019/18.7128/28.130.0188/0.020833.84/37.440.6
 2566/6.479/8.6613/13.0517/17.4636/26.260.0088/0.009715.84/17.461.0
400111914/13.4718/18.4128/27.7637/37.1055/55.80.0374/0.041267.32/74.161.6
 211013/12.7017/17.0226/25.6634/34.2050/51.580.0173/0.019031.14/34.202.5
5001185  45/4.1555/57.6885/86.740.0581/0.0641104.58/115.38
 2180  40/41.9955/57.6885/86.740.0283/0.031250.94/56.16
6001269  60/62.785/83.88125/126.130.0845/0.0932152.10/167.76
 2266  60/32.0580/82.94125/14.720.0418/0.046175.24/83.98
7001379  90/88.41120/118.17175/177.710.0091/0.1313214.38/236.34
 2358  85/83.51110/111.62165/167.850.0562/0.0620101.16/111.60
8001511  120/119.20160/159.16240/239.600.1605/0.1770288.90/318.60
 2488  115/113.83150/152.16230/228.810.0767/0.0845138.06/152.10
9001649  150/151.39200/202.36305/304.30.2039/0.2248367.02/404.46
 2630  145/146.96195/196.44295/295.400.0990/0.1091178.20/196.38
10001805  185/187.78250/251.00375/377.450.2529/0.2788455.22/501.74
 2792  185/184.75245/246.95370/371.360.1244/0.1374223.92/246.96
